Cooling Capacity: 4.5 ton
-
BTU/hr: 54,000
- Capacity based on 45°F water outlet temp.; 10°F delta t @ 95°F ambient temperature
-
Reservoir Capacity: 30.4 Gallons
Capacities
Cooling Capacity: 4.5 ton
BTU/hr: 54,000
Capacity based on 45°F water outlet temp.; 10°F delta t @ 95°F ambient temperature
Reservoir Capacity: 30.4 Gallons
Dimensions
Width: 26 in
Depth: 51.6 in
Height: 55.1 in
Shipping Weight: 563 lbs
Installed Weight: 765 lbs
Electrical
Volts/Phase: 460/3
Hz: 60
FLA: 19
Compressor(s) for each circuit: 1
Fan(s): 1
Misc Specifications
Refrigerant: R410A
Water Flow (min/max): 5.8/ 21.2 gal/min
Available Head Pressure (min/max): 43.2/ 29.7 psi
Protection Class: IP 54
Total air flow: 3590 cfm
Total absorbed power : 6.14 kW
Pump Power : 0.75 kW
Fan Power: 0.76 kW
