Cooling Capacity: .99 ton
-
BTU/hr: 11,904
- Capacity based on 45°F water outlet temp.; 10°F delta t @ 95°F ambient temperature
-
Reservoir Capacity: 7 Gallons
Capacities
Cooling Capacity: 0.99 ton
BTU/hr: 11,904
Capacity based on 45°F water outlet temp.; 10°F delta t @ 95°F ambient temperature
Reservoir Capacity: 7 Gallons
Dimensions
Width: 22.6 in
Depth: 26.3 in
Height: 30.9 in
Weight: 184 lbs
Electrical
Volts/Phase: 230/1
Hz: 60
FLA: 14
Compressor(s): 10.8
Fan(s): 0.68
Pump(P3): 2.8
Misc Specifications
Refrigerant: R2404A
Protection Class: IP 32
Max. Absorbed Power kW: 0.86
Pump Power kW: 0.33
Fan Power (each) kW: 0.186
