Cooling Capacity: 13.7 ton
-
BTU/hr: 164,400
- Capacity based on 45°F water outlet temp.; 10°F delta t @ 95°F ambient temperature
-
Reservoir Capacity: 70 Gallons
Capacities
Cooling Capacity: 13.7 ton
BTU/hr: 164,400
Capacity based on 45°F water outlet temp.; 10°F delta t @ 95°F ambient temperature
Reservoir Capacity: 70 Gallons
Dimensions
Width: 29.9 in
Depth: 73.3 in
Height: 54.7 in
Shipping Weight: 992 lbs
Installed Weight: - lbs
Electrical
Volts/Phase: 460/3
Hz: 60
FLA: 49
Compressor(s) for each circuit: 1
Fan(s): 2
Misc Specifications
Refrigerant: R410A
Water Flow (min/max): 20.1/ 83.2 gal/min
Available Head Pressure (min/max): 42.1/ 25.0 psi
Protection Class: IP 54
Total air flow: 9415 cfm
Total absorbed power : 17.7 kW
Pump Power : 0.75 kW
Fan Power: 1.03 kW
